    Nylon Bush 65kg Capacity Open Mill Rubber Mixing 220V 380V

    Ask Lasest Price
    Brand Name : honghesheng
    Model Number : XK400
    Certification : CE
    Price : 17200USD/SET
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100SETS/MONTH
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Nylon Bush 65kg Capacity Open Mill Rubber Mixing 220V 380V

    Electrical Heated Standard Type Open Mill 50HRC 60HRC For Rubber And Plastic

    1.Technical spec.:

    ModelXK-400XK-450XK-550XK-560

    Working diameter

    of rolls(mm)

    400450550560/510
    Working length of rolls(mm)1000120015301530

    Working linear speed of

    front roll(m/min)

    18.6524.522.5

    Speed ratio of front and

    rear roll

    1:1.271:1.271:1.21:1.2
    Max. gap (mm)10101515
    Max. Capacity per batch(kg)18-3525-5050-6550-65
    Driving motor power(kw)455511090
    Overall size(L*W*H) mm4200*1850*18705200*2380*17706500*2180*18806500*2300*2000
    Around weight(ton)7.911.42222.5

    2.Features:

    1).Hardened gears reducer ,low noise ,high quality ,competitive price

    2).The machine main uses are following in rubber product factory: Natural rubber refining, raw rubber and compound mixing. Rubber beating, mixing and rubber tab letting.

    3).This machine is double roller opening to be used for rubber mixing. It consists of seat, Frame, Rubber, Driving device, Lubricator and cooler, range adjusting device of roller. Safety brake, Motor and reducer, etc.

    4).The roller is made from safety cooled and hard cast steel, smooth surface is polished. in term of different case. Saturated steam and cooling water can be inputted in the empty roller to adjust speed of roller. Colloidal particles are drawn into the gap of the two rollers which make relative rotation in different velocity to mix rubber


    3.Optional device.:

    1.Electric regulating nip

    2.Automatic stock blender

    3.Double extension shafts and universal coupling for transmission.
